KTC-175MM linear position sensor / 175MM transducer scaler electrical ruler for injection molding machine | Электронные

---

KTC-150MM linear position sensor / 150MM linear position transducer / scaler / electrical ruler  for injection molding machine

KTC	mm	75	100	110	125	150	175	200	225	250	275	300	325	350	360	375	400	425
Availbale power stroke(A.E)	mm	75	100	110	125	150	175	200	225	250	275	300	325	350	360	375	400	425
resistance ±10%	kΩ	5.0
Independent linear rate	± %	0.05
Mechanical stroke(M.T)	mm	82	107	117	132	157	182	207	232	257	282	307	332	357	367	382	407	432
resolution		infinite
Max working speed	m/s	10
current	mA	≤ 2
temperature range		60~+150
size	mm	155	180	190	205	230	255	280	305	330	355	380	405	430	440	455	480	505



KTC series	mm	450	475	500	550	600	650	700	750	800	850	900	950	1000	1150	1250
Available power stroke (A.E)	mm	450	475	500	550	600	650	700	750	800	850	900	950	1000	1150	1250
resistance ±10%	kΩ	5.0				10.0									20.0
Independent linear rate	± %	0.05
Mechanical stroke(M.T)	mm	457	482	507	557	607	657	707	757	807	857	907	957	1007	1157	1257
resolution		infinite
Max working speed	m/s	10
current	mA	≤ 2
Temperature range		60  150
size A	mm	530	555	580	630	680	730	780	830	880	930	980	1030	1080	1230	1330

  General rod type linear displacement sensor series, effective stroke 75 mm to 1250 mm, both ends are 3.5 mm buffer stroke, accuracy of 0.08% ~ 0.04% FS.Built-in conductive plastic measurement unit, with functions of automatic electrical grounding.Protection grade for IP67, using DIN430650 standard silver plated plug socket.Linkage end has 0.5 mm automatic to function, allow limit movement speed for 10 m/s.PR electronic scale series used in injection molding machine, die-casting machine, bottle blowing machine, shoes machine, woodworking machinery, printing machinery, packaging machinery, paper machinery, mechanical steering, aircraft, ship sTeering, IT equipment such as automatic control field.With optional ball universal head or fish-eye universal head, can reduce installation by a team of neutral and bring bad effects.Because the PR series electronic ruler in performance and  KTC series is very close, and also has a very high cost performance, so also for use by the broad masses of users. PR-map Operating temperature : -60-150 Life :> 100X106 times Waterproof corrosion resistance : IP60 Use speed : 10m / s MAX Shock factor : IEC 68-2-6: 1982 20g Impact factor : IEC 68-2-29: 1968 50g   1.We will ship the items within 2 working days after the payment is reached 2. We often ship to customers by UPS/DHL/Fedex and ect,We would like to ship to you which is convenient to you. Please contact us directly and we will use your preferred ways. 3. we only ship according to the shipping address unless you contact us to change it. About Return 1.All returns must be informed before returning. 2.The Buyer is ought to notify the seller of all returned items within 7 days after receiving the package. We reserve the right refusing any requirement that informs the seller longer than 7 days. 3.Exchange due to buyer wrong part ordered, buyer needs to pay 2-ways shipping fee. 4.Return items must have all original packaging and in good condition. 5.Return postage and insurance charge is non-refundable for refund or new shipment. 6.Shipping fees are non-refundable. About feedback 1.If you are pleased with your purchase, please leave us positive feedback once receiving the item, and we will return the feedback upon you. 2.If you have any problem with the outcome of the transaction or product, please don't respond with negative feedback before contacting us. we will do our best to resolve your case ASAP.  3.if you meet any questions,pls contact me first,i will try to solve for you. Negative feedback is not acceptable before contacting me.
