Skycom T-108H Optical Fiber Fusion Splicer FTTH Fiber Optic Splicing Machine with Automatic Heat Oven   Key Features >  5 inches high resolution colorful LCD display, image can be turned according to position >  Average splice time: 8 seconds >  Average tube-heat time: 25 seconds >  Automatic heat mode >  Lithium battery: Rechargable and up to 200 times of continuous splice and heat after fully charged >  X or Y axis Separately views with 360 times magnification, or Simultaneously 220 times  >  Cutting-edge technology for image processing >  New technology of fiber core alignment, enhanced accuracy, PAS Technology >  New developed technology providing strong wind and dust resistance >  Automatic self-inspection: Display inspection, Forward inspection >  Cleave length: 9~16mm (∮0.25mm)﹑10~16mm (∮0.9mm) >  Splicing mode: Auto & Manual & Full-Auto >  Storing 6,000 groups of latest splice results >  New technology of fiber core alignment, enhanced accuracy >  New 3-in-1 cutting fixture for rubber-insulated wire, pigtail & bare fiber (Patented technology) >  New Multipurpose 1+N fixture (Patented technology) * 1+N: one 3-in-1 fixture ( for rubber-insulated wire, fiber optic pigtail, bare fiber) & optional fixtures ( for SC/LC/FC connector).   Specification Applicable Fibers SM, MM, NZ-DS, EDF, Pigtail, Cable (rubber-insulated wire), SC/LC/FC connector (optional function) Average Splice Loss 0.02dB(SM), 0.01dB(MM), 0.04dB(NZDS), 0.04dB(EDF) Return Loss ≥60dB Tension Test 2.0N(200gf)(Standard) Typical splicing time 10 seconds Typical heating time 30 seconds Splicing Program 50 groups Protection Sleeve Length 20mm, 40mm, 60mm Operating Language Chinese, English, French, Portuguese, Spanish Operating Conditions -10~+50°C(operation temperature),0~95% RH(humidity), 0~5000m(altitude) Power Supply AC adaptor: 100~240V input voltage, 50/60Hz; 12V, 5A output voltage(DC)  Inner lithium battery: 12V, 5.2AH Monitor 5 inches high resolution colorful LCD display Fiber Image Magnification X or Y axis Separately views 360 times magnification, or Simultaneously 220 times Storage of Splice Result 6,000 groups of latest splice results Splicing Model Auto & Manual & Full Auto Optical Fiber Fixture 3-in-1 cutting fixture; Multipurpose 1+N fixture (T-208HF, for SC/LC/FC connector) Dimensions 130(W)*135(D)*130(H)mm;                 Package size: 53*32*30cm Weight 1.74kg+0.38kg (battery weight)=2.12kg;        Package G.W.: 6.03 kg   Standard Accessories No. Item Quantity 1 Machine T-108H x1 2 Fiber Cleaver x1 3 Fiber Stripper x1 4 AC Adaptor (Charger) x1 5 Battery x1 6 Spare Electrodes x1 7 Cooling Tray x1 8 Instruction CD x1 9 Quick Reference Guide x1 10 Rubber-insulated wire stripping pliers x1 11 Rubber-insulated wire 3-in-1 cutting fixture x1 12 Carrying Case with Carrying Strap x1 *Custom-made Professional anti-shock tool kit (case) with sponge inside  *Export-standard Carton Box with PE Foam inside (53*32*30cm)

Product Pictures:
