| Camera |
| Image Sensor: |
| |
1/3" Progressive Scan CMOS |
| Signal System: |
| |
PAL/NTSC |
| Min. Illumination: |
| |
Color: 0.01 Lux @ (F1.2, AGC ON) B/W: 0.001 Lux @ (F1.2, AGC ON) |
| Shutter time: |
| |
1 s to 1/100,000 s |
| Lens Mount: |
| |
C/CS mount |
| Auto Iris: |
| |
DC drive(-P: support P-Iris) |
| Day& Night: |
| |
IR cut filter with auto switch |
| Wide Dynamic Range: |
| |
120 dB |
| Digital noise reduction: |
| |
3D DNR |
| Focus: |
| |
ABF(-A model) |
| Compression Standard |
| Video Compression: |
| |
H.264+/H.264/MPEG4/MJPEG |
| Video bit rate: |
| |
32Kbps~16Mbps |
| Audio Compression: |
| |
G.711/G.722.1/G.726/MP2L2 |
| Triple Streams: |
| |
Yes |
| Image |
| Max. Image Resolution: |
| |
1280x960 |
| Frame Rate: |
| |
WDR OFF: 50Hz: 25fps (1280 × 960), 50fps (1280 × 720) 60Hz: 30fps (1280 × 960), 60fps (1280 × 720) WDR ON: 50Hz: 25fps (1280 × 960), 25fps (1280 × 720) 60Hz: 30fps (1280 × 960), 30fps (1280 × 720) |
| Third Stream: |
| |
Independent with Main Stream and Sub Stream, up to 50Hz: 25fps(1280 × 960) 60Hz: 30fps (1280 × 960) |
| Image Settings: |
| |
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
| BLC: |
| |
Support |
| Smart Defog: |
| |
Support |
| EIS: |
| |
Support |
| ROI: |
| |
Support |
| Picture Overlay: |
| |
128 × 128, BMP 24bit, zone configurable |
| Network |
| Network Storage: |
| |
NAS (Support NFS,SMB/CIFS) |
| Alarm Trigger: |
| |
Line crossing detection, Intrusion detection, Defocus detection, Scene change detection, Motion detection, Face detection, Dynamic analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception |
| Protocols: |
| |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
| General Function: |
| |
User Authentication, Watermark, IP address filtering, anonymous access, flickerless, heartbeat, video mask |
| System Compatibility: |
| |
ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
| Interface |
| Audio Input: |
| |
1-ch 3.5 mm audio interface, Mic in/Line in. 1 built-in Microphone |
| Audio Output: |
| |
1-ch 3.5mm audio interface (line level, 600 Ω) |
| Communication Interface: |
| |
1 RJ45 10M/100M Ethernet port, 1 RS-485 interface and 1 RS-232 interface |
| Alarm Input: |
| |
1 |
| Alarm Output: |
| |
1 |
| Video Output: |
| |
1Vp-p Composite Output (75 Ω, BNC) |
| On-board storage: |
| |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Reset Button: |
| |
Yes |
| Wi-Fi Specification (-W) |
| Wireless Standards: |
| |
IEEE802.11b, 802.11g, 802.11n |
| Frequency Range: |
| |
2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth: |
| |
20/40MHz Support |
| Modulation Mode: |
| |
802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM |
| Security: |
| |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Transmit Power: |
| |
11b: 17±1.5dBm @ 11Mbps 11g: 14±1.5dBm @ 54Mbps 11n: 12.5±1.5dBm |
| Receive Sensitivity: |
| |
11b: -90dBm @ 11Mbps (Typical) 11g: -75dBm @ 54Mpbs (Typical) 11n: -74dBm (Typical) |
| Transmission Rate: |
| |
11b: 11Mbps 11g: 54Mbps 11n: up to 150Mbps |
| Wireless Range: |
| |
50m(depend on environment) |
| General |
| Operating Conditions: |
| |
-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
| Power Supply: |
| |
24V AC, ±10% / 12V DC, ±10% , PoE(Power Over Ethernet) |
| Power Consumption: |
| |
Max. 6 W (Max. 9W with IR cut filter on) -W: Max. 7 W (Max. 10W with IR cut filter on) |
| Dimensions: |
| |
69.8×58×145 mm (2.68” × 2.56” × 5.70”) |
| Weight: |
| |
830 g (1.83 lbs) |
