1. The stepper motor driver chip is made by new Toshiba original TB67S109, the latest model, internal BiCD process, and CLOCK-in control bipolar stepper motor drive.   2. The rated maximum output is 4A, 50V, low output impedance 0.49, built-in error detection circuit (TSD), over-current shutdown (ISD), and power-on reset (POR) error detection (TSD/ISD) signal output function.   3, suitable for 42, 57, 60, 86 size series of stepper motors less than 4A (recommended to use less than 4A residual), not suitable for stepper motors over 4A.   9) automatic half flow, automatic attenuation.   10) subdivide: whole step, half step, 1/4 step, 1/8 step, 1/16 step, 1/32 step, maximum 32 subdivision.   The integrated IC of this product uses all new raw materials, the current can be adjusted by 0.5A-4A in 8 grades, and the power resistance adopts precise patch. Quality assurance, very low profit, no bargaining, no technical support, set up wiring boards directly bid buyers can read carefully before buying, need a certain electronic technology foundation, products are full-test PASS.
