Raspberry Pack 3 Generation 3b Extension Board RS485 SPI CAN Bus Module UART Communication | Инструменты



Сохраните в закладки:

Цена:2 203,74RUB
*Стоимость могла изменится

Количество:


Новое поступление

Hennybig Fish Store

Hennybig Fish Store

Магазина Hennybig Fish Store работает с 26.07.2018. его рейтинг составлет 90.02 баллов из 100. В избранное добавили 1084 покупателя. Средний рейтинг торваров продавца 4.6 в продаже представленно 2681 наименований товаров, успешно доставлено 1680 заказов. 441 покупателей оставили отзывы о продавце.

Характеристики

Raspberry Pack 3 Generation 3b Extension Board RS485 SPI CAN Bus Module UART Communication | Инструменты

История изменения цены

*Текущая стоимость 2 203,74 уже могла изменится. Что бы узнать актуальную цену и проверить наличие товара, нажмите "Добавить в корзину"

Месяц Минимальная цена Макс. стоимость Цена
Feb-19-2026 2798.12 руб. 2854.79 руб. 2826 руб.
Jan-19-2026 2269.80 руб. 2314.64 руб. 2291.5 руб.
Dec-19-2025 2754.17 руб. 2809.14 руб. 2781.5 руб.
Nov-19-2025 2732.70 руб. 2787.51 руб. 2759.5 руб.
Oct-19-2025 2181.64 руб. 2225.74 руб. 2203 руб.
Sep-19-2025 2688.76 руб. 2742.54 руб. 2715 руб.
Aug-19-2025 2666.97 руб. 2719.8 руб. 2692.5 руб.
Jul-19-2025 2644.73 руб. 2697.61 руб. 2670.5 руб.

Описание товара

Raspberry Pack 3 Generation 3b Extension Board RS485 SPI CAN Bus Module UART Communication | ИнструментыRaspberry Pack 3 Generation 3b Extension Board RS485 SPI CAN Bus Module UART Communication | ИнструментыRaspberry Pack 3 Generation 3b Extension Board RS485 SPI CAN Bus Module UART Communication | Инструменты


modname=ckeditor

Copyright ownership, infringement must be investigated. It shall not be used for commercial purposes without permission. \



  Raspberry pie RS485 CAN expansion board \

Product Brief

[A word of self-introduction]

I am the RS485, CAN expansion board designed for raspberry pie.

What do I mainly do?

Are you still worried about the lack of 485 and CAN interfaces for raspberry pie?
Want your raspberry pie to communicate reliably over long distances with other devices?
Well, I'm the right person to look for. I'm tailored for it.

[my characteristics]

  • Raspberry Pi Zero/Zero W/Zero WH/2B/3B/3B+\
  • CAN function, using SPI interface CAN controller MCP2515, with transceiver SN65HVD230\\
  • RS485 function, UART control, half-duplex communication, transceiver SP3485
  • Reserve control interface for other controllers to control\
  • Provide a complete set of information manuals (wiringPi and python routines)
[my parameters]

  • Operating Voltage: 3.3V\
  • CAN Controller: MCP2515
  • CAN Transceiver: SN65HVD230
  • 485 transceiver: SP3485
  • Product Size: 65mm x 30mm
  • Fixed aperture: 3.0m

Product pictures

详1

Function pin Raspberry interface (BCM) describe
3V3 3V3 3.3V power supply is positive.
GND GND Power ground
SCK P11 / SCLK SPI clock input
MOSI P10 / MOSI SPI data entry
MISO P9 / MISO SPI data output
CS P8 / CE0 SPI chip select signal
INT P25 Interrupt output
RXD P15 / RXD RS485 serial port reception
TXD P14 / TXD RS485 serial port sending
RSE P18 RS485 set transceiver

Product information


The information includes:


  • User manual
  • Schematic diagram
  • Sample program
  • Development materials

Outline size





Configuration list


  1. RS485 CAN HAT × 1
  2. RPi Copper Column Package (2PCS Set) & times;


1
