KEBIDU Universal RF Transmitter 433 Mhz Remote Controls Wireless Control Switch DC 12V 1CH relay Receiver Module | Электроника

KEBIDU Universal RF Transmitter 433 Mhz Remote Controls Wireless Control Switch DC 12V 1CH relay Receiver Module | Электроника

• Input Voltage: 12 V, RF working mode: Superheterodyne
• Receiver sensitivity: > 97 dbm
• Transmitting distance:> 100 m ( open space)
• Decoding mode: MCU software decoding
• Remote storage: 20
• Support remote type: EV1527 learning code
• Working mode: Momentary, toggle, latching time delay (5s ,10s ,15s )
• Output terminal: NO , NC , COM
• Dimension of PCB:35 x 30 x 18 mm (L,W,H)
• Remote control battery: 2 x 3 V CR2016 button batteries
Note: Maximum input power is 250 V   Remote programming -Clearing the code :
Push the learning button on the receiver 8 times , the codes will be reset.
After clearing the code, remotes will be need to be recalibrated   -Momentary mode Please contact us for detailed use instructions   -Learning the code : ( Toggle - Press remote button to turn on, press again to turn off.)
Press the learning key on the receiver 2 times, Wait for a moment , the LED will be off , it comes into learning state .   -Push the learning key on the receiver 3 times , the LED (on the Receiver)will blink 3 times.
When the LED is on, press the button of the remote control(You want to let it learn), Push the remote button A, LED flash for 3 times .
Push the remote button B, Led flash for 3 times .
After 3 seconds , the LED indicator will be off , Learning to succeed.   Package including Remote Control   *1   （just one Remote Control）
