Professional CZE-T251 0-25W adjustable FM stereo transmitter broadcast radio station NJ connector | Radio & TV Broadcasting Equipment

Brand NameCZERFModel NumberCZE-T251OriginMainland ChinaCertificationCEPackageNoVoltage12VMeasurement unitpiece/piecesSold insell_by_pieceEach pack1Package weight1.820Package size - length (cm)23Package size - width (cm)20Package size - height (cm)1020 790,00 ₽20 790,00 ₽Add to CartBuy now20 790,00 ₽

Delivery to Moskva g

Delivery to a Post office

Self-pickup

4,7

All stars

• Meekay U.28 November 2022

  The transmitter works really well. my only gripe is it will not transmit below 1w. The unit shows 0w power until it's adjusted above 1w.audio and build quality is brilliant. but it really should say 1-25w

  Show more1
• Dariusz L.14 November 2022
  Show more
• Michel A.10 October 2022
  Show more

Description

Professional  CZE-T251 0-25W adjustable FM stereo transmitter broadcast radio station NJ connector

Features:

CZE-T251 25Wt FM transmitter is a professional FM transmitter newly released by Fmuser . It’s featured by one button control for all functions. It has VSWR protection, temperature protection, electronic volume adjusting,equipped with low pass filters. It’s applicable in many places, such as stadium, county radio station, community radio station, motel, public square,church, theater and so on.

Specificationand:

-215mm x 165mm x 54mm chassis

-Power up to 25 watts

-Using digital phase-locked loop frequency synthesizer (PLL) technology, ultra-high frequency stability.

-Have the standing wave protection, and overtemperature protection.

-Output power from 0 ~ 25W continuously adjustable

-Using the RF power lock feature

-Show the timely output power and various working status.

Electrical parameters:

RF part:

Operating frequency: 87.5 ~ 108MHz

Output power: 0-25Watt (continuously adjustable)

Output Impedance: 50 ohm

Spurious and harmonic radiation:-60db

RF connector: NJ type


Audio part:

Frequency response: 50 ~ 15KHz (3db)

Distortion: 0.2%

Left and right channel separation: 45db

LINE IN connector: RCA two-channel Cinch (stereo)

The microphone interface: 6.5mm

Microphone Type: Dynamic microphone (electret microphone is not applicable)

Power supply part:

Rated working voltage: DC 12~13.8V 5A/6A

Maximum power consumption: 60W

Operation Attentions:

1. Make sure the antenna or the Load can be ground connected to transmitter

2. The power supply voltage must be within the allowed range.

3. Make sure the fan ventilation is good.

Note:

1. Before place order please you have gp2 outdoor antenna with NJ connector cable for it.
2. When using please connect antenna first ,then connect the power supply, otherwise, transmitter will be burned out.
3. Select an unused frequency in your area.
4. Packing not included power supply and Antenna.

Packing included:
CZE-T251 25W FM Transmitter x1
